Item Number: 26610
Basket Litter Stretcher  | | Catalogue Page #: 172
Product Description- Durable steel basket stretcher for handling and extrication procedures
- Durathene netting allows water and air to easily pass through the patient compartment.
- Can be used with lifting bridle set, basket stretcher mattress and backboard.
- Includes three patient restraint straps.
- Dimensions: 62.2 x 210 x 17.1 cm (24-1/2" x 82-3/4" x 6-3/4"); weight: 15 kg (33 lbs); capacity: 409 kg (900 lbs)
View Material Safety Data Sheet
|
Item Number: 26619
Basket Litter Stretcher Dust Cover  | | Catalogue Page #: 173
Product Description- 100% vinyl stretcher case with two reinforced nylon webbing handles
- Case keeps stretcher clean and protected from harmful elements
- Unzips 3/4 of the way around its circumference to allow for easy access
- For use with Items 26615 & 26616
|
Item Number: 26611
Basket Litter Stretcher Lifting Bridle  | | Catalogue Page #: 172
Product Description- Heavy-duty bridle set complete with O-ring and extra strength double-locking snaps. Snaps are made of forged steel and are plated to CSA standards
- For use with basket stretcher (Item 26610)
- Breaking strength - for webbing: 2,955 kg (6,500 lbs); for hardware: 2,272 kg (5,000 lbs)
|
Item Number: 26613
Basket Litter Stretcher Mattress  | | Catalogue Page #: 172
Product Description- Vinyl-covered foam mattress provides added comfort to the victim
- For use with a basket stretcher ( Item 26610)
- Dimensions: 177.8 x 40.6 x 2.5 cm (70" x 16" x 1")
|
Item Number: 26616
Basket Litter Stretcher w/Aluminum Frame/Plastic Shell & Restraint Straps  | | Catalogue Page #: 172
Product Description- Consists of frame, shell and straps only
- Used with backboard (Items 26163, 26454 or 26455)
- Can be used with lifting bridle set (Item 26611)
- Litter frame supports in excess of 1,136 kg (2,500 lbs)
- Working range temperature: -50° Celsius to 82° Celsius (-60° Fahrenheit to 180° Fahrenheit)
- Dimensions: 206 x 63.5 x 20 cm (81" x 25" x 8"); weight: 18 kg (40 lbs)
|
Item Number: 26615
Basket Litter Stretcher w/Aluminum Frame/Plastic Shell, Bed Insert, Restraint Straps & Lifting Bridle  | | Catalogue Page #: 173
Product Description- Full body restraint system for handling and extrication procedures
- Provides complete protection and minimizes transmitted shock and impact to the patient, even when carried through brush, rough terrain, ice or snow
- Patient can be moved in any position with added security and minimal discomfort
- Consists of: basket litter complete with lightweight aluminum frame; spring suspended, vinyl-coated nylon bed insert; security envelopment system; three restraining straps; heavy-duty polyethylene shell
- Double security envelopment system consists of: nylon shoulder straps; patient over-flaps; adjustable, padded pelvic support harness; head and chin immobilizing flaps with harness; three back-up side release securing straps; nylon foot and ankle straps; four nylon lifting straps; and a large storage pocket
- Bed insert may be used with spinal backboard (Items 26163, 26454 or 26455), splints and mast trousers
- Litter frame supports in excess of 1,136 kg (2,500 lbs)
- Capacity of nylon lifting straps: 1,818 kg (4,000 lbs)
- Working range temperature: -50° Celsius to 82° Celsius (-60° Fahrenheit to 180° Fahrenheit)
- Dimensions: 206 x 63.5 x 20 cm (81" x 25" x 8"); weight: 18 kg (40 lbs)
|
|
|
|
